2.4Ghz N300 Wireless Extender (Repeater) external antenna
Extender N3A
Introducing our 2.4GHz N300 Wireless Extender (Repeater) with an External Antenna, a powerful solution to
expand your wireless network coverage. This device operates at the 2.4GHz frequency and offers N300 speeds
for reliable connectivity. With its external antenna, it ensures extended range and improved signal strength.
Easily set it up to enhance your existing Wi-Fi network, eliminating dead spots and providing seamless coverage.
Whether it's for home or office, enjoy improved connectivity for your devices with this efficient wireless
extender.
• Extensive 300M Wireless Range Extension
• Equipped with an External Omni-Directional
Antenna
• Features a Single LAN Port for Connectivity
• Adheres to IEEE 802.11n, IEEE 802.11g, and IEEE
802.11b Standards
• 802.11n WLAN for Speedy Wireless Access at 300Mbps,
Ideal for Streaming, Gaming, and VoIP
• Effortless Installation with the Easy Setup Assistant
• User-Friendly Interface Allows for Free WEB Software
Updates
• Supports Long-Distance Transmission: Up to 100 meters
indoors, 300 meters outdoors (depending on
environmental factors)
Description
Interface
• Chipset: Realtek RTL8196E
• Interface:
1x10/100 Mbps
• Wireless Mode : AP/ Repeater
• Antenna: 2x 2dbi fixed antenna
• Wireless Signal Rates With Automatic Fallback:
11n: Up to 300Mbps (Dynamic)
11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic)
• Standard: 802.11n, IEEE 802.11g, IEEE 802.11b
• Frequency Range :2.4-2.4835GHz
• Wireless Transmit Power: <20dBm(EIRP)
• Modulation Type : OFDM/CCK/16-QAM/64-QAM
• Receiver Sensitivity :
2.4GHz 802.11b:
- 1Mbps, -97dBm, ± 2dB
- 11Mbps, -90dBm, ± 2dB
2.4GHz 802.11g:
- 6Mbps, -92dBm, ± 2dB
- 54Mbps, -76dBm, ± 2dB
2.4GHz 802.11n: 20MHz MCS0, -92dBm, ± 2dB
- MCS7, -75dBm, ± 2dB
- MCS8, -71dBm, ± 2dB
2.4GHz 802.11n: 40MHz MCS0, -89dBm, ± 2dB
- MCS9, -67dBm,, ± 2dB
• Wireless Security: 64/128 bits WEP, WPA/WPA2,
WPA-PSK/WPA2-PSK (TKIP/AES)
• Operating Temperature: -20°C~70°C
• Storage Temperature: -40°C~90°C
• Relative Humidity: 5% ~ 95%, non-condensation
• Storage Humidity: 5%~90% non-condensing
Standard package of switch
• Product size:
8.2 x 7.2 x 5.5cm (L*W*H)
Weight: ≤TBD
Package size:
TBD cm(L*W*H)
• Package content
Extender N3A/QIG
Ordering information
• AirLive Extender N3A
2.4Ghz N300 Wireless Extender (Repeater),
external antenna
